Description
AOC U28G2X/D 28″ 4K Gaming Monitor
Experience an immersive gaming experience with U28G2X/D. The 28” 4K Ultra HD IPS panel display is equipped with DisplayHDR 400 with 95% DCI-P3 gamut, delivering lifelike color reproduction with wide viewing angles. Its 144 Hz refresh rate, 1ms response time and HDMI 2.1 offers everything you need to be on top of the game, paving
Brilliant visuals with ultra detailed pictures
4K Ultra High-Definition (3840 x 2160) resolution delivers ultra-crisp picture quality and allows users to see more on the screen at one time. This provides more screen ‘real estate’ and also shows more detail for sharper and more brilliant images. Whether working on the next beautiful photo, design, or even just used for productivity, users will marvel at the true, crisp image that only a UHD display can provide.
FreeSync Premium delivers ultra-smooth tear-free gaming
Screen tearing and stuttering doesn’t only harm gaming performance, it also destroys immersion. AMD FreeSync Premium addresses this by keeping your monitor’s refresh rate synced with your processor’s.
Enjoy top-tier gaming performance
With a 144Hz refresh rate , your display will be equipped to perform at the pro gaming standard. Enjoy an ultra-smooth experience with no visible screen blur to ensure you’re always prepped to win.
Instant response times
A pixel response time of 1ms MPRT means speed without the smear for an enhanced gaming experience. Fast-moving action and dramatic transitions will be rendered smoothly without the annoying effects of ghosting. Choose the right path to gaming success, and never let a slow display stop you.
Designed with wide viewing angles
IPS displays deliver 178/178-degree viewing angles while maintaining consistent image quality and colors from all viewing positions. You can also view your spreadsheets or weekend movies from virtually any angle without compromising color uniformity.
HDMI 2.1 expands the limits of possibility
HDMI 2.1 brings faster and variable refresh rates and amazing 48Gbps transmission bandwidth, for reduced or eliminated lag, stutter and frame tearing, plus higher resolution, higher frame rates, and smooth, fluid and detailed up to 4K120Hz gaming experience.
VESA Certified DisplayHDR 400
VESA-certified DisplayHDR 400 delivers a significant step-up from normal SDR displays. Unlike, other ‘HDR compatible’ screens, true DisplayHDR 400 produces astonishing brightness, contrast and colors. With global dimming and peak brightness up-to 400 nits, images come to life with notable highlights while featuring deeper, more nuanced blacks. It renders a fuller palette of rich new colors, delivering a visual experience that engages your senses.
| Model name | U28G2X/D |
| Panel | 28″ (IPS) |
| Pixel Pitch (mm) | 0.16 (H) x 0.16 (V) |
| Effective Viewing Area (mm) | 620.9 (H) x 341.28 (V) |
| Brightness (typical) | 300 cd/m² |
| Contrast Ratio | 1000 : 1 (Typical) 80 Million : 1 (DCR) |
| Response Time | 1ms (MPRT) |
| Viewing Angle | 178° (H) / 178° (V) (CR > 10) |
| Color Gamut | NTSC 104% (CIE1976) / sRGB 116% (CIE1931) / DCI-P3 95% (CIE1976) |
| Color Accuracy | Delta E < 2 |
| Optimum Resolution | 3840 × 2160 @ 144Hz – DisplayPort1.4，HDMI2.1 |
| Display Colors | 16.7 Million |
| Signal Input | HDMI 2.1 × 2 / DisplayPort 1.4 × 2 |
| HDCP Version | HDMI: 2.2, DisplayPort: 2.2 |
| USB Hub | no |
| Power Supply | 100 – 240V ~ 1.5A, 50 / 60Hz |
| Power Consumption (typical) | 45W |
| Speakers | no |
| Line in & Earphone | – |
| Wall-Mount | 100mm x 100mm |
| Adjustable Stand | Height: 130mm, Pivot: 0°~90° ± 2°, Swivel: -30° ~30°, Tilt: -5° ~ 23° |
| Product without Stand (mm) | 368.5 (H) x 636.4 (W) x 53.0 (D) |
| Product with Stand (mm) | 401.9~531.9 (H) × 636.4 (W) × 227.4 (D) |
| Product without Stand (kg) | 4.81 |
| Product with Stand (kg) | 6.15 |
| Cabinet Color | Black & Red |
| Regulatory Approvals | RCM / MEPS / CE / CB / FCC |
| *. To enable UHD@144Hz, a graphics card which supporting DSC must be used. Please visit the graphics card manufacturer’s website for DSC support | |
| *U28G2X/D has been upgraded to AMD Freesync Premium version since June.01.2022 (manufactured date). |
