| Screen Size |
27 inch |
| Panel Type |
IPS |
| Backlight Technology |
LED backlight |
| Resolution (max.) |
2560×1440 |
| Brightness (typ.) |
300 nits |
| HDR |
HDR10 |
| Native Contrast |
1000:01:00 |
| Viewing Angle (L/R) (CR>=10) |
178°/178° |
| Response Times (GtG) |
5 ms |
| Refresh Rate (Hz) |
60 |
| Color Gamut |
100% sRGB, 97% P3, 99% AdobeRGB |
| Color Mode |
Adobe RGB, B+W, Calibration 1, Calibration 2, Calibration 3, Custom1, Custom2, DCI-P3, DICOM, Display P3, HDR, M-Book, Rec.709, sRGB |
| Aspect Ratio |
16:09 |
| Display Colors |
1.07 billion colors |
| PPI |
109 |
| Display Screen Coating |
Anti-Glare |
| Color Temperature |
5000K, 6500K, 9300K, Custom, User Define |
| Gamma |
1.6 – 2.6, sRGB |
| HDCP |
2.2 |
| OSD Language |
Arabic, Chinese (simplified), Chinese (traditional), Czech, Deutsch, English, French, Hungarian, Italian, Japanese, Korean, Netherlands, Polish, Portuguese, Romanian, Russian, Spanish, Swedish |
| AMA |
Yes |
| Screen Size |
27 |
| Panel Type |
IPS |
| Backligh Technology |
LED backlight |
| Resolution (max.) |
2560×1440 |
| Brightness |
300 |
| Native Contrast(typ.) |
1000:1* |
| Viewing Angle (L/R;U/D) (CR>=10) |
178/178 |
| Response Time |
5 ms (GtG) |
| Refresh Rate |
60Hz |
| Aspect Ratio |
16:09 |
| Display Colors |
1.07 billion colors |
| Color Gamut |
99% AdobeRGB, 97% P3, 100% sRGB |
| Display Area(mm) |
596.7×335.6 |
| Pixel Pitch (mm) |
0.2331 |
| PPI |
109 |
| DCR (Dynamic Contrast Ratio) (typ.) |
20M:1 |
| Audio |
|
| Headphone Jack |
Yes |
| Headphone Jack |
Yes |
| Power |
|
| Voltage Rating |
100 – 240V |
| Power Supply |
Built-in |
| Power Consumption (normal) |
36.1 W |
| Power Consumption (max) |
150 W |
| Power Consumption (sleep mode) |
<0.5 W |
| Power Delivery(USB C / Thunderbolt 3) |
60 W |
| Voltage Rating |
100~240V |
| Power Supply |
Built-in |
| Power Consumption (based on Energy Star) |
36.1W |
| Power Consumption (stand by mode) |
0.5W |
| Power Consumption (sleep mode) |
0.5W |
| Dimension and Weight |
|
| Tilt (down/up) |
-5˚ – 20˚ |
| Swivel (left/right) |
45˚/ 45˚ |
| Pivot |
90˚ |
| Height Adjustment Stand |
150 mm |
| Dimensions (HxWxD) (mm) |
505-611.45×613.8×285.3 |
| Dimensions (HxWxD) (inch) |
19.9-24×24.2×11.2 |
| Dimensions (HxWxD) (w/o Base) (mm) |
368.9 x 613.8 x 62.7 |
| Dimensions (HxWxD) (w/o Base) (inch) |
14.5×24.2×2.5 |
| Dimensions (HxWxD) (w/o Base) (with shading hood) (mm) |
372.2 x 626 x 238 |
| Dimensions (HxWxD) (w/o Base) (with shading hood) (inch) |
14.7×24.6×9.4 |
| Dimensions(HxWxD) (with shading hood) (mm) |
505-614.8 x 626 x 334.8 |
| Dimensions(HxWxD) (with shading hood) (inch) |
19.9-24.2×24.6×13.2 |
| Net Weight (kg) |
10.3 |
| Net Weight (lb) |
22.7 |
| Net Weight (w/o Base) (kg) |
6.5 |
| Net Weight (w/o Base) (lb) |
14.33 |
| Net Weight (with shading hood) (kg) |
10.6 |
| Net Weight (with shading hood) (lb) |
23.36 |
| VESA Wall Mount |
100×100 mm |
| Dimensions (HxWxD mm) (w/o Base) (with shading hood) |
372.2 x 626 x 238.04 |
| Dimensions(HxWxD mm) (without shading hood) |
Landscape: 504.5-611 x 613.8 x 213.4 |
|
Portrait: 733.4 x 380.7 x 223.2 |
| Dimensions (HxWxD mm) (w/o Base) |
368.9 x 613.8 x 62.65 |
| Dimensions (HxWxD mm) |
Landscape: 504.5-614.3 x 626 x 334.8 |
|
Portrait: 744.6 x 381.1 x 334.6 |
|
9.5 |
| Net Weight (kg) (without shading hood) |
|
| Net Weight (kg) (without stand) |
Landscape: 6.5 |
|
Pivot: 6.8 |
| Net Weight (kg) |
H: 10.6 |
|
Pivot: 10.9 |
| Gross Weight (kg) |
18.4 |
| Tilt (down/up) |
-5˚/- 20˚ |
| Swivel (left/right) |
45/45 |
| Pivot |
90˚ |
| Height Adjustment (mm) |
150mm |
| Accessories |
|
| Other Accessories |
Calibration Report, Hotkey Puck G2, QSG, Shading Hood ( Landscape ), Warranty Card |
| Connectivity |
|
| Card Reader |
SD/SDHC/SDXC/MMC |
| HDMI (v2.0) |
2 |
| DisplayPort (v1.4) |
1 |
| USB C(PowerDelivery 60W, DisplayPort Alt Mode, Data) |
1 |
| USB Type B ( Upstream ) |
1 |
| USB 3.1 ( Downstream ) |
2 |
| HDMI |
HDMI (v2.0)x2 |
| DisplayPort |
DisplayPort (v1.4) |
| Card Reader |
SD/MMC type |
|
Support Format: SD/SDHC/SDXC/MMC |
| Certification |
|
| calman verified |
Yes |
| Pantone Validated |
Yes |
| Pantone SkinTone™ Validated |
Yes |
| Calman Verified |
Yes |
| Calman Ready |
Yes |
| Pantone Validated |
Yes |
| Professional |
|
| Video Format Support |
Yes |
| Factory Calibration Report |
Yes |
| 3D-LUT |
16bits |
| Delta E(avg) |
≤2 |
| Gamut Duo |
Yes |
| Black & White mode |
Yes |
| Black Level |
Yes |
| Hardware Calibration |
Yes |
| Hotkey Puck G2 |
Yes |
| PIP/PBP |
Yes |
| 3D-LUT |
16bits |
| Delta E |
≦ 2 (average) |
| Uniformity Technology |
Yes |
| Hardware Calibration |
Yes |
| Video Format Support |
Yes |
| Gamut Duo |
Yes |
| Black & White mode |
Yes |
| Black Level |
Yes |
| Hotkey Puck G2 |
Yes |
| Factory Calibration Report |
Yes |
| Software |
|
| Palette Master Element |
Yes |
| LightSpace Ready |
Yes |
| calman ready |
Yes |
| Palette Master Element |
Yes |
| Accessory Dimension and Weight |
|
| Dimensions (HxWxD) (mm) |
505-611.45×613.8×285.3 |
| Dimensions (HxWxD) (inch) |
19.9-24×24.2×11.2 |
| Net Weight (kg) |
10.3 |
| Net Weight (lb) |
22.7 |
| Monitor |
|
| Segment |
Photographer |
| Product Color |
Gray |
| Color Mode |
Adobe RGB / sRGB / B&W / Rec. 709 / DCI-P3 / Display P3 / M-book / HDR / DICOM/Calibration 1 / Calibration 2 / Calibration 3 / Custom 1 / Custom 2 |
| HDR |
HDR10 |
| Display Mode |
Full, Aspect Ratio, 1:1 |
| Color Temperature |
5000°K / 6500°K/ 9300°K / Custom/ User Defined |
| Gamma |
1.6 – 2.6, sRGB |
| K Locker |
Yes |
| OSD Language |
18 Languages (English / Francais / Deutsch / Italiano / Espanol / Polish / Czech / Hungarian / Romanian / Dutch / Russian / Swedish / Protuguese / Japanese / Chinese / S-Chinese / Arabic/Korean) |
| PIP/PBP |
Yes |
| HDCP |
2.2 |
| VESA Wall Mount |
100x100mm |
| AMA |
Yes |
| Display Screen Coating |
Anti-Glare |
| Video Signal Data |
|
| Hor. Frequency (KHz) |
27~140Khz |
| Ver. Frequency (Hz) |
24~76Hz |
| Video Bandwidth (MHZ) |
600M Hz |
| Included Accessories |
|
| Other Accessories |
Shading hood (Landscape), QSG, Factory Calibration Report ,Hotkey Puck G2 |
| Power Cable |
Yes(1.8m) |
| Signal Cable |
USB type-C cable(1m), mDP to DP cable (1.8m), HDMI 2.0 cable (1.8m), USB 3.1 cable (Gen 1)(1.8m) |
| Reliability |
|
| Operating Temperatur |
0˚C – 40˚C |
| Operating Humidity (non-condensing) |
10% – 90% |
| Compatibility |
|
| Mac Compatible |
Yes |
| Windows® Compatible |
Windows®10, Windows®8.1, Windows®8, Windows®7 |
