ZU1300 -14400 lUMENS WUXGA DLP Laser Projector
ZU1300
High brightness WUXGA DLP laser projector 14,400 lumens
DuraCore laser technology Up to 30,000 hours laser light source
Dust resistant Independently tested, IP6X certified for total reliability
Installation flexibility7 interchangeable lens options including an ultra short throw lens
Download Catalog PDF Click here>
Description
ZU1300 14,400 lumens WUXGA DLP laser projector
DuraCore
Industry leading lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.
IP6X Airtight optical engine
Independently tested and certified to IEC standard 60529 with an IP6X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; paramount for 24/7 maintenance free operation in challenging environments.
Integrated warping and edge blending processor
Integrated warping and edge blending processor enables multiple projectors to be warped and blended without additional dedicated hardware, reducing the cost & complexity of installation. Warping and edge blending is configured using either the projectors on screen display or with PC software depending on model.
*Compatible multi output graphics card with overlap function is required.
HDR compatible
Capable of receiving and displaying HDR meta data, Optoma HDR compatible projectors allow you to see far more detail and texture. Objects look more solid and life like and the extra detail creates a greater sense of depth. It’s like looking through a window.
HDBaseT™
Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT- type cable capable up to 100 meters/328 feet without signal loss makes installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.
Amazing colour
Optoma projectors provide reliable colour performance suitable for any content and environment. From accurate sRGB colours for lifelike images to vibrant punchy presentations. We have a display mode to specific meet your needs. Perfect for a range of graphic and video presentations.
Colour Management System (CMS)
Display accurate lifelike colours to best match your viewing environment. This unique feature provides you with the flexibility to fine-tune the colour settings of your projector for optimal precision.
Brightness matching
A valuable feature of any professional installation incorporating more than one projector. Multiple units of the same model and similar lamp usage can be fine tuned to give the same brightness levels; important, especially when side by side.
Constant power
Allows users to set the power levels to meet individual installation requirements. Power levels can be managed to obtain the brightest picture or longest light source life – or anywhere inbetween
Constant brightness
Advanced light sensing technology allows the setting of brightness levels that will remain unchanged over time. Ideal for ensuruing constant brightness for fine tune installations
True AV mute
True AV mute enables the light source of the projector to be instantly switched off and on at the press of a button. Unlike standard AV mute functionality no light is emitted from the projector, this gives 100% blackout on screen.
Extreme Black
Extreme black enables the laser diodes to completly turn off when a full black image frame is detected. This feature is perfect for situations where a total image blackout is required.
Full lens shift
Full lens shift makes installation simple and hassle free, offering the flexibility to move the projected image vertically or horizontally, as well as adjusting the screen size without the need to move or reposition the projector.
Picture by picture picture-in-picture
Signals can be delivered simultaneously via the HDMI and DVI ports, for a PbP or PiP display from two digital sources – perfect for video-conferencing and other collaborative applications.
360 projection*
With 360° projection,* images can be displayed in any orientation, giving you the freedom and versatility to install this projector in the desired location.
*For more information please refer to the user manual
Portrait projection
Ideal for digital signage applications you can rotate your projector 90 degrees to project a portrait image.
Customise your projector
Have your projector in any colour. Choose from any RAL colour. Perfect for bespoke installations. *Contact us for more information
Full 3D
Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.
Wired remote
The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector; invaluable when using multiple units during live events.
Control
Featuring a wide range of options you can control and monitor the projector remotely.
• RS232 Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.
• AMX compatible Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
• Crestron RoomView Using the compatible RoomView® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer
• Extron IPLink compatible Allows for easy installation with Extron control systems
PJLink
PJLink protocol is incorporated into the projector allowing for easy installation with PJLink compatible control systems.
Telnet
This model is able to receive comands via telenet allowing for easy installation with Telnet compatible control systems.
Gallery
Specification
Display/image
| Display technology |
DLP™
|
| Resolution |
WUXGA (1920×1200)
|
| Brightness |
14,400 lumens
|
| ANSI brightness |
12,000
|
| Contrast ratio |
2,000,000:1
|
| Native aspect ratio |
16:10
|
| Aspect ratio – compatible |
4:3,16:9,16:10
|
| Keystone correction – horizontal |
+/-20°
|
| Keystone correction – vertical |
+/-20°
|
| Uniformity |
90%
|
| Screen size |
Dependent on lens
|
Lamp info
| Light source type |
Laser
|
| LASER life |
30,000 hours
|
Optical
| Throw ratio |
Dependent on lens
|
| Projection distance (m) |
Dependent on lens
|
| Lens options |
BX-CTA16- 0.36 ~ 0.36
BX-CTA17- 0.65~0.75 BX-CTA15- 0.75 ~ 0.95 BX-CTA01- 0.95 ~ 1.22 BX-CTA06- 1.22 ~ 1.52 BX-CTA03- 1.52 ~ 2.92 BX-CTA13- 2.90 ~ 5.50 |
| Lens shift |
Yes – {{downloads_link}}
|
Connectivity
| Connections |
|
General
| Noise level (min) |
37dB
|
| Noise level (max) |
39dB
|
| PC compatibility |
HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible
|
| 2D compatibility |
PAL (625/576i/p), SECAM, NTSC (525/480i/p), HDTV (720p, 1080i/1080p)
|
| 3D compatibility |
Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
|
| 3D |
Full 3D
|
| Security |
Security bar, Kensington Lock
|
| IP rating |
IP6X
|
| OSD / display languages |
11 languages: Dutch, English, French, German, Indonesian, Italian, Japanese, Portuguese, Russian, Chinese (simplified), Spanish
|
| 24/7 operation |
Yes
|
| 360° operation |
Yes
|
| Operating conditions |
5°C~40°C/41°F~104°F, max altitude M/0ft, max humidity 10-85%
|
| Remote control |
Wired ProAV remote
|
| In the box |
AAA Battery, AC power cable 3M, Lens cover, VGA cable 1.8m, User manual CD, Quick start guide
|
| Optional wireless models |
QuickCast Bundle, QuickCast starter kit
|
Networking
| LAN |
Yes
|
Power
| Power supply |
100 – 240V, 50 – 60Hz
|
| Power consumption (standby) |
0.5W
|
| Power consumption (min) |
465W
|
| Power consumption (max) |
955W
|
Weight and dimensions
| Dimensions (W x D x H) mm |
484 x 529 x 208
|
| Gross weight |
27 kg
|
| Net weight |
21 kg
|
