Description

DISPLAY

Panel Technology	PLS TFT with W-LED backlight
Screen Size [inch/cm]	27 / 68
Screen Aspect Ratio	16:9
Colour Gamuts	100 % sRGB; 75 % NTSC
Pixel Pitch [mm]	0.233
Brightness (typ.) [cd/m²]	350
Contrast Ratio (typ.)	1000:1 (7000:1 dynamic contrast ratio)
Viewing Angle [°]	178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms]	6
Colours [Mio.]	16.78

SYNCHRONISATION RATE

Horizontal Frequency [kHz]	31.5 – 94
Vertical Frequency [Hz]	56 – 75

RESOLUTION

Optimum Resolution	2560 x 1440 at 60 Hz
Supported	2560 x 1440;1920 x 1440;1920 x 1080;1600 x 1200;1280 x 1024;1152 x 864;1024 x 768;832 x 624;800 x 600;640 x 480

CONNECTIVITY

Digital

1 x DisplayPort; 1 x DisplayPort out; 1 x HDMI; 1 x USB Type C (60 W); 1x DVI-D (Dual Link); USB ver. 3.1 (3 down / 2 up)

ELECTRICAL

Power Consumption on Mode [W]	150 (max.); 30 (Eco Mode 2); 37 (Eco Mode 1); 37 (shipping); 37 (typ.)
Power Savings Mode [W]	0.35
Power Supply	0.75 A/1.6 A; 100-240 V; internal power supply

ENVIRONMENTAL CONDITIONS

Operating Temperature [°C]	+5 to +35
Operating Humidity [%]	20 to 80
Storage Humidity [%]	10 to 85
Storage Temperature [°C]	-10 to 60

ERGONOMICS

Height adjustable stand [mm]	150
Screen Tilt [°]	-5 to 35
Screen Swivel [°]	-170 to +170
Screen Rotate [°]	-90 to 90 (landscape to portrait mode)

MECHANICAL

Bezel Width [mm]	1 (left/right/top)
Dimensions (W x H x D) [mm]	361.9 x 628.6 – 652.1 x 250 (Portrait mode); 611.8 x 378 – 528 x 250 (Landscape mode)
Weight [kg]	With stand: 9.1; Without stand: 5.7
VESA Mounting [mm]	100 x 100

ADDITIONAL FEATURES

Special Characteristics	Ambient light sensor for optimized brightness levels; Carbon Footprint Meter; Carbon Savings Meter; ControlSync®; Customize Setting; DisplayPort; EcoModes; ErgoDesign®: Height adjustable stand (150 mm) with 90° Pivot features; Human Sensor; LED Backlight Technology; NaViSet Administrator 2; Picture-by-Picture; Quick release Stand and Handle; TileMatrix; Touch Sensor Keys; USB ver. 3.1 (3 down / 2 up); Versatile and easy installation (VESA standard) with NaViSet and NaViKey
Colour Versions	Black Front Bezel, Black Back Cabinet; White Front Bezel, White Back Cabinet
Cable Management	yes
Kensington security slot	yes
Plug and Play	DDC2B/2Bi; EDID Standard; VESA DDC/CI
Audio	1W + 1W (De-activateable); Headphone Jack
Adjust Functions	Audio Volume / Lock-Out; Auto Adjust; Brightness; Colour Temperature Control; Contrast; Control Sync; DV Mode; EcoMode; Human Sensing; Intelligent Power Management; Language Select; Monitor Information; On-Screen-Display (OSD) lock-out; One Touch Recovery; Power-Off Timer
Shipping Content	Control Sync Cable; DisplayPort cable; Monitor; Power Cable; Setup Guide; USB Cable
Safety and Ergonomics	CE; EAC; ErP; ISO 9241-307 (pixel failure class I); PSB; RoHS; TCO 7.0; TCO Certified Edge Displays 1.2.; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA
Warranty	3 years warranty incl. backlight; optional 4th to 5th year warranty extension

GREEN FEATURES

Energy Efficiency	Ambient light sensor; ECOMode; Energy efficiency class: A; Human sensor
Ecological Materials	Minimal use of harmful material
Ecological Standards	Energy Star 7.1; ErP compliant; RoHS compliant; TCO 7.0; TCO edge
