NEC PA703W WXGA Professional Installation Projector

NEC PA703W Professional Installation Projector Features:

NEC PA703W

Professional Installation Projector

Type LCD
Brightness [AL] 7000
Resolution 1280 x 800
Light Source Lamp
Light Source Life [h] 5000
Weight [kg] 10.2
Order Code 60004080

Description

NEC PA703W WXGA Professional Installation Projector Description

If extraordinary visualisation, brilliant colours and superb dynamic contrast is key for your business, then the NEC PA703W should be your first choice.

The compact 7,000 ANSI lumen LCD projector with WXGA resolution not only trumps the competition with its unique colour processing technology, but also in its outstanding installation capabilities where motorized lens shift, focus and zoom makes setup effortless. The unique HDBaseT-out interface enables multiple projector daisy chaining via cost efficient network cables to a single source helping to reduce installation costs. Like a multi-tool, the essential features continue with management of the latest copyright protocol to play 4k and Ultra HD Blu-ray content whilst the long lamp life and even longer filter life earn a most attractive Total Cost of Ownership.

All in all the NEC PA703W projector is perfectly suited for meeting-, lecture- and seminar-rooms in corporate and higher education installations.

  • Cinema Quality Visualisation – enjoy excellent picture quality even in bright ambient light conditions with unique picture & colour processing technology (up to up to 4K/60Hz) based on the latest NEC scaler chip.
  • Hassle-free remote adjustment – motorized lens shift, focus and zoom allows easy and flexible setup without the need for cumbersome physical access to the projector.
  • Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, picture in picture, tiling, 3D support and camera based blending/stacking up to 4K.
  • Impress with brilliant colours & contrast – astound your audience as the projector processes a wider colour space with Rec2020 to Rec709 colour conversion and higher dynamic contrast supporting HDR10 standard via HDMI interface.
  • Peace of mind copyright protected content – let the projector manage copyright protection and present 4k and Ultra HD Blu-ray content via the HDMI interface.

NEC PA703W WXGA PROFESSIONAL PROJECTOR – IMAGE

Projection Technology 3LCD Technology
Native Resolution
1280 x 800 (WXGA)
Aspect Ratio 16:10
Contrast Ratio 1 8000:1
Brightness 1 7000 ANSI Lumen (approx. 80% in Eco Mode), with std. optional lense
Lamp 370 W UHP AC (280 W UHP AC Eco Mode)
Lamp Life [hrs] 4000 (5000 Eco Mode)
Lens 3 motorized lens options; 5 manual lens options
Lense Adjustment Motorized and manual (depending on lens)
Keystone correction +/- 40° manual horizontal / +/- 40° manual vertical
Projection Factor depending on lens selection (std. option NP41ZL at 1.3-3.02:1)
Projection Distance [m] 0.7 – 50.9
Screen Size (diagonal) [cm] / [inch] (best performance range); Maximum: 1,270 / 500″
Zoom Motorized and manual (depending on lens)
Focus Adjustment Motorized and manual (depending on lens)
Supported Resolutions
4096 x 2160 (4k);2560 x 1600 (WQXGA);2048 x 1080 (2k);1920×1200 (WUXGA) – 640×480 (VGA);1080i/50/60;1080p/24/25/30/50/60;720p/60;720p/50;576i/50;576p/50;480p/60;480i/50
Frequency Horizontal: analog: 15/24-100 kHz, digital: 15/24-153 kHz; Vertical: analog: 48-120 Hz, digital: 48-120 Hz

CONNECTIVITY

RGB (analog) Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr)
Digital Input: 1 x DisplayPort; 1 x HDBaseT; 2 x HDMI™ supporting HDCP 2.2
Output: 1 x HDBaseT supporting HDCP 2.2
Audio Input: 1 x DisplayPort Audio support; 1 x HDBaseT audio support; 2 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio support
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
Control Input: 1 x 3.5 mm Stereo Mini Jack (Wired Remote); 1 x D-Sub 9 pin (RS-232), Ethernet
LAN 1 x RJ45
USB 1 x Type A (USB 2.0 high speed)
3D Sync Output: 1 x Mini DIN 3pin

REMOTE CONTROL

Remote Control 3D Setup; Aspect Ratio; Audio Control; Auto Adjust; DisplayPort; Eco Mode Control; Edge-Blending; Freeze-function; Geometric Correction; HDMI; Help-function; Magnify-function; Multiscreen; Page (up, down); PBP/POP Function; Picture Adjust; Picture Mute; PIP Function; Power (On-OFF); Select (up, down, left, right); Source Select; Test Picture

GREEN FEATURES

Energy Efficiency ECO scheduler; Intelligent Power Management; Less than 0.3W Stand-By power; Longer lamp life; Software scheduling; Timer-Function
Ecological Materials 100% recyclable packaging; Downloadable manuals
Ecological Standards ErP compliant



WARRANTY

Projectors 3 years pan-European service
Light Source 6 months, max. 1000 hrs

SHIPPING CONTENT

Shipping Contents IR Remote Control (RD – 466E); Power Cord; Projector; Quick Setup Guide; Users Manual on CD-ROM

OPTIONAL ACCESSORIES

Optional Accessories 8 optional bayonet lenses; Air Filter (NP06FT); Cable Cover (NP10CV); Ceiling Mount Kit; Lamp (NP42LP); MultiPresenter Stick; XpanD 3D Glasses (X105-RF-X2); XpanD 3D RF Emitter (AD025-RF-X2)
Lenses – motorized NP40ZL (0.79-1.11:1); NP41ZL (1.3-3.02:1); NP43ZL (2.99-5.93:1)
Lenses – manual NP11FL (0.81:1); NP12ZL (1.16-1.52:1); NP13ZL (1.46-2.95:1); NP14ZL (2.9-4.68:1); NP30ZL (0.79-1.04:1)
