NEC X554HB 55″ LED Backlit High Brightness Display
NEC X554HB 55″ LED Backlit High Brightness Display
| Panel Technology | SPVA | Viewable Image Size | 55 “ |
| Aspect Ratio | 16:9 | Native Resolution | 1920×1080 |
| Pixel Pitch | 0.63 mm | Pixels Per Inch | 40 |
| Backlight Type | LED Direct-lit | Brightness (typical) | 2000 cd/m2 |
| Brightness (maximum) | 2700 cd/m2 | Contrast Ratio (typical) | 5000:1 |
Description
NEC X554HB 55″ LED Backlit High Brightness Display
The LED backlit 55″ NEC X554HB offers superior brightness, extended runtimes and advanced engineering necessary for digital signage and messaging in high ambient light applications. This is the ideal display for window-facing retail signage where the sun may directly affect the fidelity of picture quality for a normal television or dimmer display. It can also be used for quick serve restaurant menuboard applications when coupled with a weatherproof type of enclosure. Direct LED backlighting combined with an integrated ambient light sensor allows for adaptable panel brightness depending on environmental conditions. This means that if the display senses higher lux during brighter hours of the day, the display will show a brighter image. At night when the ambient light is much less, the display will dim down, saving overall power consumption. Special quarter lambda polarizer is integrated onto the panel of this display that allows for the display to be seen in any type of orientation even when a customer is wearing polarized sunglasses. This display is the ideal solution for installations where high brightness is a necessity.
- Direct LED backlighting combined with an integrated ambient light sensor allows for adaptable panel brightness depending on environmental conditions. This means that if the display senses higher lux during brighter hours of the day, the display will show a brighter image. At night when the ambient light is much less, the display will dim down, saving overall power consumption.
- 2700cd/m² max brightness combined with full HD resolution will capture the attention of the audience in bright environments
- Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allows for 24/7 operation
- Built-in expansion slot supports the Open Pluggable Specification (OPS)
- Real-time clock has the ability to set schedules for on/off times 24/7
- Free software solution that greatly eases administration and management of larger display device installations
- Near field communication capabilities for setup and service. More information can be found here
Display
Panel Technology SPVA Viewable Image Size 55 “ Aspect Ratio 16:9 Native Resolution 1920×1080 Pixel Pitch 0.63 mm Pixels Per Inch 40 Backlight Type LED Direct-lit Brightness (typical) 2000 cd/m2 Brightness (maximum) 2700 cd/m2 Contrast Ratio (typical) 5000:1 Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 Response Time (Gray to Gray) 6 ms Refresh Rate 60Hz Active Screen Area 47.6 x 26.8 in. / 1209.6 x 680.4mm Orientation Landscape/Portrait Displayable Colors More than 16.7 million
