Optoma ZU1700 17000 lumen WUXGA laser projector

Optoma ZU1700 17000 lumen WUXGA laser projector

High brightness WUXGA DLP laser projector

Extreme installation flexibility

Ultimate reliability

Striking lifelike images



Description

Optoma ZU1700 17000 lumen WUXGA laser projector

Ultra bright professional WUXGA laser projector

The high brightness ZU1700 professional laser projector fills a need for high-end installations, including the entertainment, exhibition, and digital signage markets. Part of Optoma’s Ultra Bright Series, this projector offers incredibly high brightness of 17,000 lumens as well as extreme flexibility with eight interchangeable lenses to meet the needs of even the most complex installations.

As part of the Optoma DuraCore laser line up, the Ultra Bright Series high-performance projectors feature 4K HDR compatibility, pure engine video processing and colour matching to produce visually striking, lifelike images with exceptional detail and high colour accuracy.

Strong reliability is at the core of the Ultra Bright Series projectors, with 24/7 operation capabilities, up to 30,000 hours of laser lifetime, and an IP5X rating for optimal and dependable performance, even under more extreme conditions up to 122 degrees Fahrenheit / 50 degrees Celsius. With a robust metal chassis and modular design for easier maintenance, a multitude of connectivity options, and failsafe redundancy mode for instant source switching, the Ultra Bright Series projectors offer a solution for intricate installations, including multi-projector and dome projection applications.

Specification

Display/image

Display technology
DLP
Resolution
WUXGA (1920×1200)
Brightness
17,000 lumens
ANSI brightness
14,500
Contrast ratio
2,000,000:1
Native aspect ratio
16:10
Aspect ratio – compatible
16:9,16:10
Screen size
Dependent on lens

Lamp info

Light source type
DuraCore Laser
LASER life
30,000 hours

Optical

Throw ratio
Dependent on lens
Projection distance (m)
Dependent on lens
Lens options
BX-CTA11, 0.65~0.75:1
BX-CTA18, 0.84~1.02:1
BX-CTA19, 1.02~1.36:1
BX-CTA20, 1.2~1.5:1
BX-CTA21, 1.5~2.0:1
BX-CTA22, 2.0~4.0:1
BX-CTA23, 4.0~7.2:1
BX-CTA27, 7.2~10.8:1

Connectivity

Connections
Inputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDBaseT, 1 x DisplayPort, 2 x HDMI, 1 x VGA, 1 x DVI-D, 1 x 3G-SDI
Outputs 1 x RS232, 1 x 3D sync, 1 x Wired remote, 1 x HDMI, 1 x 3G-SDI
Control 1 x RJ45, 1 x USB-A service, 1 x 12V trigger

General

Noise level (typical)
36dB
Noise level (max)
38dB
3D
Full 3D
IP rating
TBC
OSD / display languages
12 languages: Dutch, English, French, German, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Spanish
24/7 operation
Yes
360° operation
Yes
Operating conditions
Operating: 10~85%RH, non-condensing. Storage: 5~90%RH, non-condensing
Remote control
Backlit ProAV remote

Networking

LAN – display
Yes
LAN – wireless networking
No
LAN
Yes

Power

Power supply
AC 100–240 V @ 50/60 Hz
Power consumption (standby)
0.5W
Power consumption (min)
460W
Power consumption (max)
1,000W

Weight and dimensions

Dimensions (W x D x H) mm
650 x 682 x 300.86
Gross weight
62.5 kg
Net weight
50 kg
